4" (100 MM) IMPELLER : NORYL, DIFFUSER : NORYL
Model HP Stage Outlet Head Range MRP
CW1-07 0.5 7 1.25" 21 Mtr - 59 Mtr 19010
CW1-13 1 13 1.25" 39 Mtr - 109 Mtr 24090
CW1-20 1.5 20 1.25" 60 Mtr - 168 Mtr 29600
* FLow Rate will be in Range : 10 LPM - 50 LPM *
Model HP Stage Outlet Head Range MRP
SPW5-9 1 9 1.25" 26 Mtr - 68 Mtr 19880
SPW5-14 1.5 14 1.25" 41 Mtr - 105 Mtr 22900
SPW5-18 2 18 1.25" 52 Mtr - 135 Mtr 27000SPW5-22 2.5 22 1.25" 64 Mtr - 165 Mtr 32940
SPW5-28 3 28 1.25" 81 Mtr - 210 Mtr 37800
* FLow Rate will be in Range : 10 LPM - 80 LPM *
Model HP Stage Outlet Head Range MRP
SPWR-11 1.5 11 1.5" 29 Mtr - 91 Mtr 23550
SPWR-15 2 15 1.5" 40 Mtr - 125 Mtr 27440
SPWR-22 3 22 1.5" 58 Mtr - 183 Mtr 37800
SPWR-28 4 28 1.5" 74 Mtr - 232 Mtr 41690
SPWR-36 5 36 1.5" 95 Mtr - 293 Mtr 63620
* FLow Rate will be in Range : 10 LPM - 90 LPM *
